Android 3+32G Camera Mic 4K Interactive Flat Panel 75 Inch for School Education
Product Details:
| Place of Origin: | Shenzhen, CHINA |
| Brand Name: | iBoard or OEM |
| Certification: | CCC, CE, FCC, RoHS, Reach, OHSAS, ISO9001, ISO14001 |
| Model Number: | TE-XP-86 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | USD1350-1470 |
| Packaging Details: | Carton Package |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000 units per month |
|
Detail Information |
|||
| Android Version: | 9.0 | Touch Points: | 20 Points |
|---|---|---|---|
| Operation OS: | Windows/Android/LINUX/Mac | Application: | School/office/video Meeting/training/presentation |
| Camera: | Optional | Mic: | Optional |
| Package: | Carton Box | Wireless Sharing: | Available |
| Main Frequency: | Default 1.2G | Rated Voltage: | AC(100-240)V～50/60HZ |
| Aspect Radio: | 16:10, 16:9... | Aspect Radio: | 16:10, 16:9... |
| Interface: | USB, VGA, RS232, HDMI | Screen Size: | 65",75",86", 98" |
| Multi-Touch: | Up To 40 Points | Hotkeys: | Two Sides Hotkeys |
| Shipping Way: | Sea Shipping Air Freight Truck Freight | Warranty: | 1 Year |
| Power Supply: | AC 100-240V, 50/60Hz | Operation System: | Andriod/Windows/Linux/Mac.etc. |
| Accuracy: | 2mm | Mobile Stand: | Optional |
| Mobile Stand: | Optional | Colors: | Black Or OEM |
| Highlight: | 4K interactive flat panel 75 inch,smart interactive flat panel education,DLED 20 points digital interactive panel |
||
Product Description
Interactive Flat Panel 4K Panel Display 65 75 86 Android 3+32G Camera Mic For School Kids Video meeting Training
Applications:
Our interacative whiteboard flat panel display has widely used in school, office,video meeting, training,presentation,online teaching,etc.And our workable size is 65inch,75inch,86inch,etc. OEM and ODM available.We also have technical team to provide professionl service.
Advantages:
1. Latest touch solution, with android 9 or 11 optional
2. Supporting dual OS operation:Windows/Android/Linux/Mac.
3. Supporting wireless sharing,1 upto 9 screen at one time
4. with Powerful annotation software, available to QR share/cloud save annnotation file
5. Optional to be built in 4K camera and Mic.
6. Optional to be with Face recognization/NFC/Fingerprint recognization
| Model | TE-XP-65 |
| Display type | DLED |
| Resolution | 3840*2160 |
| Brightness | 350cd/㎡ |
| Contrast ratio | 1200:1 |
| Display area | 1428.5*803.5 mm(64.53 inch) |
| Panel ratio | 16:9 |
| View angle | 178° |
| Color | 10bit,1.07 billion color |
| Video format | PAL,NTSC,SECAM |
| Sound format | D/K, B/G, I,M |
| CPU | Quad core A55 |
| Main frequency | default 1.2G |
| Andriod version | 9.0 |
| Flash | 16G/32G EMMC |
| RAM | 2G/3 DDR4 |
| VGA input resolution | 640*480/800*600/1024*768/1280*768/ 1280*800/1280*960/1280*1024/1360*768/1440*900/1600*1200/1920*1080@60Hz |
| First touch response time | <19ms |
| Input ports |
Back IO input:2*HDMI2.0(up to3840*2160/60Hz),1*VGA+AUDIO,2*USB 2.0,1*TOUCH-USB,1*RS232,1*TF,1*LAN IN(10M/100M),1*WIFI(2.4G/5G),1*Bluetooth,1*OPS(up to3840*2160/60Hz, bulid-in 10M/100M LAN) Front IO input:1*HDMI(Max supporting 3840*2160/60Hz),1*TOUCH USB,3*USB |
| Output port | Back IO OUTPUT:1*COXIAL,1*EARPHONE |
| Front keys | 11KEY(POWER,SOURCE,MENU,VOL+,VOL-,REC,A.BLUE,PC,ES,RATIO,HOME) |
| Short cut | NO |
| Rated voltage | AC(100-240)V～50/60HZ |
| Rated current | 2.5A(including OPS) |
| Working temperature | 0°C～45°C |
| Touch points | Single/Two/Four/Six/Ten points |
| Touching mode | Fingers or pen |
| Location technology | Ifrared |
| Location accuracy | <2mm |
| Location resolution | 4096*4096/16384*16384/32768*32768 |
| Continuous response time | <8ms |
| Cursor speed | >180 dot/second |
| Communication port of touch system | USB |
| Operating system | WINDOWS/LINUX/MAC /Android |
| Effective object size | ≥Φ3mm |
| Touch times | More than 60,000,000 times at one position |
| Accessory | Touch pens x 2 |
| HDMI cable(2M) x 1 | |
| Touch USB cable 1.5M x 1 | |
| Power supply cord(1.8M) x 1 | |
| Installation DVD x 1 | |
| Remote controller x 1 | |
| Warranty card x 1 | |
| Product size | 1469.1*916.6x93.2mm |
| Packing size | 1646x1074x240mm |
| N.W. | Approx.38Kg(Plastic cover) |
| G.W. | Approx.52kg |
